leaflet 结合 Echarts4 实现统计图(附源码下载)

前言

leaflet 入门开发系列环境知识点了解:

内容概览

leaflet 结合 Echarts4 实现统计图
源代码 demo 下载

本文 leaflet 结合 Echarts4 实现三种形式统计图:

  1. Leaflet Popup
  2. Leaflet Control
  3. Leaflet Marker

实现效果图如下:

  • Leaflet Popup
    通过弹出窗口实现 Leaflet,在 popup 的 popupopen 事件触发时重载 echarts
function initControl_Popup(map){
    var popChartMarker=L.marker([23.15,113.25]).addTo(map);
    //配置弹出框
    var content='<div style="width:500px;height:300px" id="mark"></div>';
    popChartMarker.bindPopup(content,{maxWidth:2000});
    popChartMarker.on('popupopen',function(e){
        var myChart=echarts.init(document.getElementById('mark'));
        var option = {
        title: {
            text: ''
        },
        tooltip : {
            trigger: 'axis',
            axisPointer: {
                type: 'cross',
                label: {
                    backgroundColor: '#6a7985'
                }
            }
        },
        legend: {
            data:['邮件营销','联盟广告','视频广告','直接访问','搜索引擎']
        },
        toolbox: {
            feature: {
                saveAsImage: {}
            }
        },
        grid: {
            left: '3%',
            right: '4%',
            bottom: '3%',
            containLabel: true
        },
        xAxis : [
            {
                type : 'category',
                boundaryGap : false,
                data : ['周一','周二','周三','周四','周五','周六','周日']
            }
        ],
        yAxis : [
            {
                type : 'value'
            }
        ],
        series : [
            {
                name:'邮件营销',
                type:'line',
                stack: '总量',
                areaStyle: {},
                data:[120, 132, 101, 134, 90, 230, 210]
            },
            {
                name:'联盟广告',
                type:'line',
                stack: '总量',
                areaStyle: {},
                data:[220, 182, 191, 234, 290, 330, 310]
            },
            {
                name:'视频广告',
                type:'line',
                stack: '总量',
                areaStyle: {},
                data:[150, 232, 201, 154, 190, 330, 410]
            },
            {
                name:'直接访问',
                type:'line',
                stack: '总量',
                areaStyle: {normal: {}},
                data:[320, 332, 301, 334, 390, 330, 320]
            },
            {
                name:'搜索引擎',
                type:'line',
                stack: '总量',
                label: {
                    normal: {
                        show: true,
                        position: 'top'
                    }
                },
                areaStyle: {normal: {}},
                data:[820, 932, 901, 934, 1290, 1330, 1320]
            }
        ]
    };
        myChart.setOption(option);
    });
}
  • Leaflet Control
    主要就是初始一个 control,并在并给其中的容器 DIV 附上 class 和 id,id 用于创建图表时能找到该容器,class 用于控制 control 的样式
    class 样式
.chart{
    width: 600px;
    height: 300px;
    background-color: #fff;
}

```
function initControl_Chart(map){
var chartCtr=L.control({position: 'bottomright'});
chartCtr.onAdd=function (map) {
var div=L.DomUtil.create('div','info chart');
div.id='chartControl';
return div;
}
chartCtr.addTo(map);
var myChartControl = echarts.init(document.getElementById('chartControl'));
var option = null;
option = {
tooltip: {
